95-21USRD/S357/TR7

LED Indication - Discrete Overview

The Everlight 95-21USRD/S357/TR7 is a surface-mount LED component featuring a gull wing package. It emits red light with a peak wavelength of 639nm and a luminous intensity ranging from 45 to 100mcd. The device operates at a forward voltage of 2V and is designed for indication applications.

LED Indication - Discrete Feature Summary

• Surface mount construction with gull wing leads
• Red light emission capability
• Diffused lens configuration

LED Indication - Discrete Applications

• General purpose electronic equipment indication
• Panel status signaling
• Indicator lights in consumer devices

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct binning and packaging specifications. Confirm that the component matches the required electrical parameters for the target circuit design before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component for applications requiring a standard red SMD indicator. Ensure the design accommodates the 2-SMD gull wing footprint and thermal requirements associated with surface mount technology for reliable long-term operation.

LED Indication - Discrete Part Context

This part belongs to Everlight's discrete LED portfolio, specifically within their surface-mounted indicator series. It serves as a fundamental optical component for visual feedback in various electronic assemblies, offering a compact solution for status monitoring.

LED Indication - Discrete Replacement Considerations

Consult official cross-reference lists for verified substitutes. Ensure any replacement maintains identical pinout, spectral characteristics, and mechanical dimensions to guarantee compatibility without redesigning the PCB layout.
