98423-F61-22LF

Headers, Male Pins Overview

The 98423-F61-22LF is a Minitek series unshrouded header manufactured by Amphenol ICC (FCI). It features 22 positions with a 2 mm pitch and two rows. The connector utilizes right-angle through-hole solder pin termination with male pin contacts. Gold plating on the copper alloy contacts ensures reliable conductivity. The thermoplastic housing is black, rated for operation between -40°C and +125°C, with a current rating of 3 A.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration
• Gold-plated copper alloy male pin contacts
• Unshrouded dual-row design

Headers, Male Pins Applications

• Board-to-Board connections
• General electronic interconnects

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Amphenol documentation to confirm contact finish and material specifications. Ensure the selected variant matches the required thermal and electrical ratings for the target application environment. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and compliance status.

Headers, Male Pins Selection Notes

Select this component for applications requiring right-angle board-to-board connectivity with a 2 mm pitch. The unshrouded design allows for compact stacking but requires careful alignment during assembly. Verify that the mating connector is compatible with the 22-position, dual-row format and appropriate contact length.

Headers, Male Pins Part Context

This component belongs to the Minitek family of connectors from Amphenol ICC (FCI), formerly Framatome Connectors International. The Minitek series provides versatile interconnect solutions for various electronic assemblies. This specific model represents a standard unshrouded header option within that product line.

Headers, Male Pins Replacement Considerations

Compatible variants include 98423-F61-10LF and 98423-G61-10LF, which share similar structural characteristics but differ in position count or specific manufacturing details. Always verify exact dimensional and electrical compatibility before substitution.
