A-SL200EA32-036-GST1

$2.00

Description：PIN HEADER, 3.60/3.20MM, 2.00MM,
Series：A-SL200
Mfr：Assmann WSW Components
Package：Tube

SKU:42659c7eda42 Category: Headers, Male Pins Brand: Assmann WSW Components

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A-SL200EA32-036-GST1 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Assmann WSW Components. Its product description is PIN HEADER, 3.60/3.20MM, 2.00MM,. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A-SL200EA32-036-GST1

Description：PIN HEADER, 3.60/3.20MM, 2.00MM,
Series：A-SL200
Mfr：Assmann WSW Components
Package：Tube
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：32
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.142" (3.60mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.087" (2.20mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：-
Contact Material：Brass
Insulation Material：Polyphenylene Sulfide (PPS)
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for A-SL200EA32-036-GST1

A-SL200EA32-036-GST1

Headers, Male Pins Overview

The A-SL200EA32-036-GST1 is a single-row board-to-board pin header manufactured by ASSMANN WSW Components. It features 32 positions with a 2.00mm pitch and utilizes surface mount right-angle termination. The contacts are constructed from brass with gold plating, housed in black PBT insulation. Rated for 1A current and 125V voltage, it operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

Surface mount right-angle design for compact PCB integration
Gold-plated brass contacts ensure reliable signal transmission
Single-row configuration simplifies board layout

Headers, Male Pins Applications

Board-to-board interconnections
High-density electronic assemblies
Consumer electronics manufacturing

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official datasheets to confirm exact pin count and termination style. Ensure compatibility with mating connectors regarding pitch and row configuration. Confirm surface mount footprint dimensions match the target PCB design before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a right-angle surface mount solution is required for space-constrained applications. The 2.00mm pitch suits standard density requirements. Verify that the 1A current rating meets the circuit load demands and that the operating temperature range aligns with the environmental conditions of the end product.

Headers, Male Pins Part Context

This part belongs to the A-SL200 series, designed for versatile interconnection needs. The series offers various configurations including different row counts and termination styles. This specific model provides a robust option for automated assembly processes due to its surface mount construction.
