A-WBP-K002DG-46TB02

A-WBP-K002DG-46TB02 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Assmann WSW Components. Its product description is WIRE-TO-BOARD, WAFER, 2.00MM, 46. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A-WBP-K002DG-46TB02

• Description：WIRE-TO-BOARD, WAFER, 2.00MM, 46
• Series：A-WBP
• Mfr：Assmann WSW Components
• Package：Bag
• Connector Type：Header
• Contact Type：Male Pin
• Pitch - Mating：0.079" (2.00mm)
• Number of Positions：46
• Number of Rows：2
• Row Spacing - Mating：0.079" (2.00mm)
• Number of Positions Loaded：All
• Style：Board to Cable/Wire
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Through Hole
• Termination：Solder
• Fastening Type：Detent Lock
• Contact Length - Mating：-
• Contact Length - Post：0.118" (3.00mm)
• Overall Contact Length：-
• Insulation Height：0.256" (6.50mm)
• Contact Shape：Square
• Contact Finish - Mating：Gold
• Contact Finish Thickness - Mating：Flash
• Contact Finish - Post：-
• Contact Material：Brass
• Insulation Material：Polyamide (PA66), Nylon 6/6
• Features：Keying Slot
• Operating Temperature：-40°C ~ 105°C
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Gray
• Current Rating (Amps)：3A
• Voltage Rating：250VAC/DC

Headers, Male Pins datasheet and documents for A-WBP-K002DG-46TB02
