A-WBP-O001DA-20TB01

Headers, Male Pins Overview

The A-WBP-O001DA-20TB01 is a connector header manufactured by Assmann WSW Components. It utilizes through-hole mounting technology and features a right-angle configuration. The component provides 20 positions with a spacing of 0.118 inches (3.00mm) from the board edge.

Headers, Male Pins Feature Summary

• Right-angle orientation for space-efficient PCB layout
• Through-hole termination method for secure attachment
• 20-position design for multi-signal connectivity

Headers, Male Pins Applications

• General electronic interconnects
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official Assmann WSW Components documentation to ensure compatibility. Confirm that the right-angle through-hole specification matches the target PCB footprint requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a right-angle connection is required for flat cable or wire-to-board applications. Ensure the 3.00mm pitch aligns with existing system design constraints and that through-hole assembly processes are available for production.

Headers, Male Pins Part Context

This component belongs to the Assmann WSW Components line of standard connectors. The company specializes in IC sockets and IDC connectors for flat cable applications, providing reliable interconnection solutions for various industrial and commercial electronic systems.

Headers, Male Pins Replacement Considerations

Consult official distributor databases for direct substitutes. Verify pin count, pitch, and mounting style compatibility before considering alternative part numbers from other manufacturers.
