A4B-5PA-2DS(71)

$0.24

Description：CONN HEADER R/A 5POS 2MM
Series：A4
Mfr：Hirose Electric Co Ltd
Package：Tray

SKU:79d65e3c942f Category: Headers, Male Pins Brand: Hirose Electric Co Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A4B-5PA-2DS(71) is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Hirose Electric Co Ltd. Its product description is CONN HEADER R/A 5POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A4B-5PA-2DS(71)

Description：CONN HEADER R/A 5POS 2MM
Series：A4
Mfr：Hirose Electric Co Ltd
Package：Tray
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：5
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Kinked Pin, Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.138" (3.50mm)
Contact Length - Post：0.102" (2.60mm)
Overall Contact Length：-
Insulation Height：0.079" (2.00mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA), Nylon
Features：-
Operating Temperature：-55°C ~ 85°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2A
Voltage Rating：200V

Headers, Male Pins datasheet and documents for A4B-5PA-2DS(71)

A4B-5PA-2DS(71)

Headers, Male Pins Overview

The A4B-5PA-2DS(71) is a right-angle pin header manufactured by Hirose Electric Co Ltd. It features a 2 mm pitch and contains five positions in a single row. The connector utilizes gold-plated brass contacts with a current rating of 1 A and a voltage rating of 200 V. Designed for through-hole soldering, it operates within a temperature range of -55°C to +85°C. The housing is constructed from black polyamide (PA) material rated UL 94 V-0.

Headers, Male Pins Feature Summary

Right-angle board mounting configuration for space-efficient assembly
Gold-plated brass contacts ensure reliable signal transmission
Polyamide housing provides thermal stability and flame resistance

Headers, Male Pins Applications

General-purpose I/O connections on printed circuit boards
Interfacing between PCBs and wire harnesses
Electronic equipment requiring compact header solutions

Headers, Male Pins Procurement Notes

Verify the specific suffix (71) against official Hirose documentation to confirm plating thickness and packaging details. Confirm end-of-life status as distributor listings indicate discontinuation. Ensure compatibility with mating wire housings from the same series before procurement.

Headers, Male Pins Selection Notes

Select this component when a right-angle, single-row header with a 2 mm pitch is required. Compare against the A4B-5PA-2DSA(71) if a straight orientation is preferred. Verify that the 1 A current rating meets the application requirements and that the through-hole soldering process aligns with manufacturing capabilities.

Headers, Male Pins Part Context

This part belongs to the Hirose A4B series, which offers miniature connectors with a 2 mm pitch. The series includes various configurations such as straight and right-angle headers in different contact counts. The A4B-5PA-2DS(71) specifically addresses needs for angled board-to-wire connections.
