AA-37.050MAGV-T

Crystals Overview

The AA-37.050MAGV-T is a quartz crystal resonator manufactured by TXC Corporation, operating at a fundamental frequency of 37.05 MHz. It features a load capacitance of 8 pF and an equivalent series resistance (ESR) of 50 Ohms. The component offers a frequency stability of ±30 ppm and operates within a temperature range of -40°C to +85°C. Housed in a compact 2-SMD, No Lead package with dimensions of 5.00mm x 3.20mm, it supports surface-mount installation. The device complies with RoHS3 standards and holds AEC-Q200 qualification for automotive applications.

Crystals Feature Summary

• AEC-Q200 qualified for automotive reliability requirements
• Fundamental mode operation for precise timing control
• Compact surface-mount design suitable for space-constrained PCB layouts

Crystals Applications

• Automotive electronic systems requiring certified timing components
• Consumer electronics utilizing surface-mount assembly processes
• Industrial control circuits needing stable frequency references

Crystals Procurement Notes

Verify that the specific part number matches the required AEC-Q200 qualification if automotive use is intended. Confirm the package type corresponds to the target PCB footprint. Ensure environmental compliance documentation aligns with regional regulations. Cross-reference the manufacturer datasheet for handling instructions regarding moisture sensitivity level. Validate supplier authenticity through authorized distribution channels.

Crystals Selection Notes

Select this component when a 37.05 MHz fundamental frequency is required with strict automotive reliability standards. The 8 pF load capacitance must match the oscillator circuit design. Consider the -40°C to +85°C operating range for harsh environments. The 50 Ohm ESR influences circuit drive level requirements. Compare physical dimensions against available board space constraints before finalizing the design.

Crystals Part Context

This crystal belongs to the AA series from TXC Corporation, designed for general-purpose and automotive applications. It provides a stable frequency reference for microcontrollers and communication interfaces. The component utilizes ceramic packaging technology for durability. It serves as a critical timing element in digital circuits where precise clock signals are necessary for synchronization and data processing operations.

Crystals Replacement Considerations

QT325G-37.050MAHV-T by QST is a documented substitute option.
