Product Detailed Parameters
- Description：LED YELLOW CLEAR SMD
- Series：-
- Mfr：Kingbright
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Yellow
- Configuration：Standard
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：15mcd
- Lens Style：Round with Flat Top
- Lens Size：2.40mm Dia
- Voltage - Forward (Vf) (Typ)：2.1V
- Current - Test：20mA
- Viewing Angle：120°
- Mounting Type：Surface Mount
- Wavelength - Dominant：588nm
- Wavelength - Peak：590nm
- Features：-
- Package / Case：2-PLCC
- Supplier Device Package：SMD
- Size / Dimension：3.20mm L x 2.80mm W
- Height (Max)：2.10mm
- Grade：-
- Qualification：-
Download product information
Overview
The AA3528YS is a single-color yellow surface-mount LED manufactured by Kingbright. It features a water-clear lens with a round flat shape and emits light at a wavelength of 588 nm. The component has a luminous intensity of 20 mcd, a forward voltage of 2.1 V, and operates at a forward current of 20 mA. Rated for 75 mW power dissipation, it measures 3.5 mm in length, 2.8 mm in width, and 1.9 mm in height. The device offers a viewing angle of 120 degrees and functions within a temperature range of -40°C to +85°C.
Feature Summary
- Emits yellow light with a 588 nm peak wavelength through a water-clear lens.
- Designed for surface-mount technology (SMD/SMT) installation.
- Provides a wide 120-degree viewing angle for broad visibility.
Applications
- PCB status indicators
- Panel indicator lights
- General-purpose visual signaling
Procurement Notes
Verify the specific part number AA3528YS against official Kingbright documentation to confirm electrical parameters such as forward voltage and luminous intensity. Ensure compatibility with RoHS standards and check moisture sensitivity levels before assembly. Confirm that the supplier provides valid datasheets matching the manufacturer's specifications to avoid counterfeit components.
Selection Notes
Select this component when a standard yellow SMD LED is required for panel or board indication. Consider the 2.1 V forward voltage and 20 mA operating current for circuit design. The 120-degree viewing angle makes it suitable for applications requiring wide visibility. Verify thermal limits and humidity sensitivity requirements for the intended environment.
Part Context
This component belongs to Kingbright's single-color LED product line, specifically utilizing the 1411 (3528 metric) package dimensions. It is part of a series offering various colors and intensities in a compact surface-mount form factor. The AA3528YS variant is optimized for yellow light emission with standard electrical characteristics common to this package type.
Replacement Considerations
The KA-3528YS is listed as an alias for this part number. Cross-reference with other 3528 package yellow LEDs from different manufacturers only if electrical parameters match exactly. Verify lens transparency and viewing angle specifications when substituting.
