AM20JW-2412SH30Z

AM20JW-2412SH30Z is listed in the DC DC Converters range at ChipApex. The manufacturer field lists aimtec. Its product description is DC DC CONVERTER 12V 20W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AM20JW-2412SH30Z

• Description：DC DC CONVERTER 12V 20W
• Series：AM20JW-Z (20W)
• Mfr：aimtec
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1.67A
• Power (Watts)：20 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 90°C (With Derating)
• Efficiency：88.50%
• Mounting Type：Through Hole
• Package / Case：6-DIP Module
• Size / Dimension：1.60" L x 1.00" W x 0.43" H (40.6mm x 25.4mm x 10.9mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for AM20JW-2412SH30Z
