AM3S-0512SH30Z

AM3S-0512SH30Z is listed in the DC DC Converters range at ChipApex. The manufacturer field lists aimtec. Its product description is DC DC CONVERTER 12V 3W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AM3S-0512SH30Z

• Description：DC DC CONVERTER 12V 3W
• Series：AM3S-Z
• Mfr：aimtec
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：250mA
• Power (Watts)：3 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 100°C (With Derating)
• Efficiency：88%
• Mounting Type：Through Hole
• Package / Case：4-SIP
• Size / Dimension：0.46" L x 0.29" W x 0.40" H (11.7mm x 7.5mm x 10.2mm)
• Supplier Device Package：4-SIP
• Control Features：-
• Approval Agency：-
• Standard Number：60950-1; 62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for AM3S-0512SH30Z
