AMPI0630ED100MT

Fixed Inductors Overview

The AMPI0630ED100MT is a shielded surface-mount power inductor manufactured by Arlitech Electronic Corp. It features an integrated molded construction with a non-standard footprint measuring 6.6 x 7.2 x 3.0 mm. The component provides an inductance of 10 µH and supports a current rating of 4.0 A. Its maximum DC resistance is specified at 68 mΩ, ensuring efficient power delivery within compact electronic designs.

Fixed Inductors Feature Summary

• Shielded magnetic design to minimize electromagnetic interference
• Integrated molded structure for mechanical stability
• Surface-mount configuration for automated assembly

Fixed Inductors Applications

• LCD panel power supply circuits
• General-purpose power filtering applications
• Compact electronic device power stages

Fixed Inductors Procurement Notes

Verify the manufacturer designation as Arlitech Electronic Corp. when sourcing this component. Confirm that the physical dimensions match the 6.6 x 7.2 x 3.0 mm specification. Ensure the part number suffix corresponds to the correct tolerance and packaging format required for your specific production line.

Fixed Inductors Selection Notes

Select this inductor for applications requiring a 10 µH value with a 4.0 A current capacity. The low DC resistance of 68 mΩ makes it suitable for efficiency-critical power paths. Consider the non-standard package size during PCB layout planning to ensure adequate clearance and soldering space.

Fixed Inductors Part Context

Arlitech Electronic Corp. specializes in inductor manufacturing, primarily serving the LCD panel industry. This component belongs to their SMD power inductor series, designed for high-current applications in consumer electronics and display technologies. The company focuses on providing reliable passive components for modern electronic systems.

Fixed Inductors Replacement Considerations

No public substitute part numbers are confirmed for this specific model. Due to the unique non-standard footprint and proprietary molding specifications, direct pin-to-pin replacements may not be available without redesigning the PCB layout.
