AP3216SYCK

LED Indication - Discrete Overview

The Kingbright AP3216SYCK is a single-color surface-mount LED from the KP-3216 series, featuring a rectangular lens with dimensions of 3.2 x 1.6 mm and a height of 1.1 mm. It emits yellow light with a peak wavelength of 590 nm and offers a nominal luminous intensity of 150 mcd. The component operates with a forward voltage of 2.5 V and supports a maximum forward current of 175 mA, while maintaining a power dissipation rating of 75 mW. It provides a wide viewing angle of 120 degrees and utilizes a water-clear lens for optimal light transmission.

LED Indication - Discrete Feature Summary

• Compact 3.2 x 1.6 mm surface-mount package design suitable for space-constrained applications
• Wide 120-degree viewing angle ensures broad visibility of indicator status
• Low power consumption characteristics support energy-efficient circuit designs
• Water-clear lens material enhances light output efficiency

LED Indication - Discrete Applications

• General purpose electronic device indicators
• Status indication on consumer electronics panels
• Backlighting applications requiring yellow illumination
• Industrial control panel signaling

LED Indication - Discrete Procurement Notes

Verify that the specific suffix matches the required color and lens type specifications for your design. Confirm RoHS compliance status through official manufacturer documentation prior to integration. Ensure handling procedures account for moisture sensitivity levels defined in the datasheet to prevent package damage during soldering processes.

LED Indication - Discrete Selection Notes

Select this component when a standard yellow SMD LED with a 120-degree viewing angle is required. Consider the 2.5 V forward voltage drop for driver circuit compatibility. Evaluate the 175 mA absolute maximum rating against thermal management capabilities in the final assembly to ensure reliable long-term operation within specified temperature ranges.

LED Indication - Discrete Part Context

This part belongs to the KP-3216 series of surface-mount LEDs manufactured by Kingbright. The series includes various colors and lens configurations sharing the same 3.2 x 1.6 mm footprint. It serves as a standard indicator solution within Kingbright's broader portfolio of optoelectronic components designed for mass production environments.

LED Indication - Discrete Replacement Considerations

APK3216SEC

LED Indication - Discrete FAQ

What is the peak wavelength of the AP3216SYCK?

The peak wavelength is 590 nm, corresponding to yellow light emission.

Does the AP3216SYCK have a wide viewing angle?

Yes, it features a 120-degree viewing angle for broad visibility.
