APDA3020LZGCK

$0.54

Description：LED GREEN CLEAR 2SMD R/A
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:3b317d7fd8b6 Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APDA3020LZGCK is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED GREEN CLEAR 2SMD R/A. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for APDA3020LZGCK

Description：LED GREEN CLEAR 2SMD R/A
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：600mcd
Lens Style：Round with Domed Top
Lens Size：1.90mm Dia
Voltage - Forward (Vf) (Typ)：2.65V
Current - Test：2mA
Viewing Angle：10°
Mounting Type：Surface Mount, Right Angle
Wavelength - Dominant：525nm
Wavelength - Peak：515nm
Features：-
Package / Case：2-SMD, No Lead
Supplier Device Package：2-SMD
Size / Dimension：3.00mm L x 2.80mm W
Height (Max)：2.00mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for APDA3020LZGCK

APDA3020LZGCK

LED Indication - Discrete Overview

The APDA3020LZGCK is a single-color green surface-mount LED manufactured by Kingbright. It operates at a forward current of 2 mA with a forward voltage of 2.65 V and a power rating of 102.5 mW. The device emits light at a wavelength of 525 nm with an optical intensity of 600 mcd. It features a dome-shaped, water-clear lens within a 3.0 mm x 2.0 mm SMD-2 package. The component has a viewing angle of 10 degrees and functions reliably between -40°C and +85°C.

LED Indication - Discrete Feature Summary

Emits high-intensity green light at 525 nm with 600 mcd output
Utilizes a compact 3.0 mm x 2.0 mm SMD-2 footprint for space-constrained designs
Features a water-clear dome lens to optimize light transmission

LED Indication - Discrete Applications

Indicator lights for electronic devices
Status displays on control panels
Low-power illumination in portable electronics

LED Indication - Discrete Procurement Notes

Verify the specific suffix 'GCK' against the manufacturer's latest datasheet to confirm lens shape and binning requirements. Ensure that the 2 mA forward current specification aligns with the target circuit design, as it differs from standard 20 mA LEDs. Confirm RoHS compliance status directly through official documentation prior to final procurement decisions.

LED Indication - Discrete Selection Notes

Select this component when a low-current, high-intensity green indicator is required. The 10-degree viewing angle provides focused visibility compared to wider-angle alternatives. Consider the 2.8 mm height constraint during PCB layout planning. This part is suitable for applications prioritizing energy efficiency and precise color rendering over broad ambient lighting.

LED Indication - Discrete Part Context

This LED belongs to the APDA3020 series, designed for surface-mount technology. It shares the standard 3020 metric dimensions with other variants in the family but distinguishes itself through specific green emission characteristics and low-power operation parameters defined by its unique suffix.
