APED3528SYC/J3

$0.80

Description：LED YELLOW CLEAR CHIP SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:ab0b7ba9daea Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APED3528SYC/J3 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED YELLOW CLEAR CHIP SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for APED3528SYC/J3

Description：LED YELLOW CLEAR CHIP SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Yellow
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：1500mcd
Lens Style：Round with Domed Top
Lens Size：2.60mm Dia
Voltage - Forward (Vf) (Typ)：2V
Current - Test：20mA
Viewing Angle：40°
Mounting Type：Surface Mount
Wavelength - Dominant：590nm
Wavelength - Peak：590nm
Features：-
Package / Case：1411 (3528 Metric)
Supplier Device Package：Chip LED
Size / Dimension：3.50mm L x 2.80mm W
Height (Max)：3.20mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for APED3528SYC/J3

APED3528SYC/J3

LED Indication - Discrete Overview

The APED3528SYC/J3 is a single-color yellow surface-mount LED from the Kingbright APED series. It features a water-clear lens with a round flat shape and emits light at a peak wavelength of 590 nm. The component has a luminous intensity of 450 mcd and operates with a forward voltage of 2 V at a test current of 20 mA. It dissipates up to 125 mW of power and functions within a temperature range of -40 °C to +85 °C. The package dimensions are 3.5 mm in length, 2.8 mm in width, and 1.9 mm in height, utilizing a 1311 (3228 metric) footprint.

LED Indication - Discrete Feature Summary

Emits yellow light with a 590 nm peak wavelength
Features a water-clear round flat lens for optical clarity
Designed for SMD/SMT assembly processes

LED Indication - Discrete Applications

General indicator lighting
Panel status indication
Consumer electronics displays

LED Indication - Discrete Procurement Notes

Verify the specific suffix J3 against the manufacturer's official datasheet to confirm tape and reel packaging specifications. Ensure the ordering part number matches the exact electrical parameters required for the circuit design. Cross-reference the RoHS compliance status with current regulatory requirements before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component when a standard 3528 form factor is required for yellow indication. Consider the 125 mW power rating and 20 mA forward current limits during thermal management planning. Verify that the 120-degree viewing angle meets the visibility requirements of the target application interface.

LED Indication - Discrete Part Context

This device belongs to the Kingbright APED series of single-color LEDs. It shares the standard 3.5 x 2.8 mm package dimensions common to the 3528 metric family. The product line offers various colors and intensities within the same physical footprint to facilitate standardized PCB layout designs across different product variants.
