Product Detailed Parameters
- Description：LED RGB CLEAR CHIP SMD R/A
- Series：-
- Mfr：Kingbright
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Red, Green, Blue (RGB)
- Configuration：Common Anode
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：220mcd Red, 50mcd Green, 100mcd Blue
- Lens Style：Round with Domed Top
- Lens Size：2.00mm x 1.00mm
- Voltage - Forward (Vf) (Typ)：1.95V Red, 2.1V Green, 3.3V Blue
- Current - Test：20mA Red, 20mA Green, 20mA Blue
- Viewing Angle：120°
- Mounting Type：Surface Mount, Right Angle
- Wavelength - Dominant：630nm Red, 570nm Green, 470nm Blue
- Wavelength - Peak：650nm Red, 574nm Green, 468nm Blue
- Features：-
- Package / Case：4-SMD, No Lead
- Supplier Device Package：Chip LED
- Size / Dimension：3.00mm L x 1.50mm W
- Height (Max)：1.00mm
- Grade：-
- Qualification：-
Download product information
Overview
The APFA3010SURKCGKQBDC is a surface-mount RGB LED from Kingbright's HeliColour series, housed in a 1204 (3.0mm x 1.0mm) package with right-angle termination. It features a common anode configuration and water-clear semitube lens. Electrical parameters include forward voltages of 1.95V (Red), 2.1V (Green), and 3.3V (Blue) at 20mA test current. Peak wavelengths are 630nm, 570nm, and 470nm respectively. Optical intensities are 220mcd, 50mcd, and 100mcd. The device operates between -40°C and +85°C with MSL level 3.
Feature Summary
- Integrates Red, Green, and Blue chips within a compact 3.0x1.0mm SMD footprint for space-constrained designs.
- Provides wide viewing angles to ensure visibility from multiple perspectives.
- Utilizes a water-clear lens to maintain color purity and optical efficiency.
Applications
- Status indication in consumer electronics
- Backlighting for portable devices
- Decorative lighting modules
Procurement Notes
Verify the specific suffix KQBDC against the official Kingbright datasheet to confirm wavelength and intensity tolerances. Ensure ESD handling protocols are followed due to moisture sensitivity level 3 classification. Confirm that the common anode pinout matches the target PCB layout before assembly.
Selection Notes
Select this component when a low-profile RGB solution is required for right-angle mounting. Compare forward voltage requirements against available drive circuits, noting the higher blue voltage. Evaluate luminous intensity needs against the specified mcd values for visibility in the intended environment.
Part Context
This part belongs to the APFA3010 family, representing Kingbright's multi-color LED portfolio. It shares the standard 1204 package dimensions with other variants in the series but differs in internal chip configuration and color output specifications defined by the unique ordering suffix.
Replacement Considerations
APFA3010SEEZGKQBKC offers similar RGB functionality but with different peak wavelengths and forward voltage characteristics. Verify electrical compatibility and mechanical fit before substitution.
