ATA01F36-L

ATA01F36-L is listed in the DC DC Converters range at ChipApex. The manufacturer field lists ARTESYN / Advanced Energy. Its product description is DC DC CONVERTER 3.3V 5W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for ATA01F36-L

• Description：DC DC CONVERTER 3.3V 5W
• Series：ATA (6W)
• Mfr：ARTESYN / Advanced Energy
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：75V
• Voltage - Output 1：3.3V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1.5A
• Power (Watts)：5 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：OCP, SCP, UVLO
• Operating Temperature：-40°C ~ 90°C (With Derating)
• Efficiency：78%
• Mounting Type：Through Hole
• Package / Case：16-DIP Module, 6 Leads
• Size / Dimension：0.94" L x 0.54" W x 0.31" H (23.8mm x 13.7mm x 8.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for ATA01F36-L
