B40920A5477M000

B40920A5477M000 is listed in the Aluminum - Polymer Capacitors range at ChipApex. The manufacturer field lists EPCOS - TDK Electronics. Its product description is CAP ALUMHYB 470UF 20% 25V SMD. Review the specifications below when checking this part for your BOM.

Aluminum - Polymer Capacitors specifications for B40920A5477M000

• Description：CAP ALUMHYB 470UF 20% 25V SMD
• Series：B40920
• Mfr：EPCOS - TDK Electronics
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Hybrid
• Capacitance：470 µF
• Tolerance：±20%
• Voltage - Rated：25 V
• ESR (Equivalent Series Resistance)：20mOhm
• Lifetime @ Temp.：4000 Hrs @ 125°C
• Operating Temperature：-40°C ~ 125°C
• Ratings：AEC-Q200
• Applications：Automotive
• Ripple Current @ High Frequency：2.8 A @ 100 kHz
• Lead Spacing：-
• Size / Dimension：0.394" Dia (10.00mm)
• Height - Seated (Max)：0.413" (10.50mm)
• Surface Mount Land Size：0.406" L x 0.406" W (10.30mm x 10.30mm)
• Mounting Type：Surface Mount
• Package / Case：Radial, Can - SMD
• Ripple Current @ Low Frequency：-
• Features：-
• Impedance：-

Aluminum - Polymer Capacitors datasheet and documents for B40920A5477M000
