B8065CN

$33.04

Description：RF ANT 836MHZ WHIP STR NMO BASE
Series：-
Mfr：TE Connectivity
Package：Bulk

SKU:938fe5f44311 Category: RF Antennas Brand: TE Connectivity

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

B8065CN is listed in the Antennas RF range at ChipApex. The manufacturer field lists TE Connectivity. Its product description is RF ANT 836MHZ WHIP STR NMO BASE. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for B8065CN

Description：RF ANT 836MHZ WHIP STR NMO BASE
Series：-
Mfr：TE Connectivity
Package：Bulk
RF Family/Standard：-
Frequency Group：UHF (300MHz ~ 1GHz)
Frequency (Center/Band)：836MHz
Frequency Range：806MHz ~ 866MHz
Antenna Type：Whip, Straight
Number of Bands：1
VSWR：2
Return Loss：-
Gain：5dBi
Features：-
Termination：NMO
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Base Mount
Height (Max)：18.000" (457.20mm)
Applications：-
Power - Max：200 W

Antennas RF datasheet and documents for B8065CN

B8065CN

Antennas RF Overview

The TE Connectivity B8065CN is a single-band whip antenna designed for UHF applications. It operates within the 806 MHz to 866 MHz frequency range, with a center frequency of 836 MHz. The component provides a peak gain of 5 dBi and maintains a VSWR of 2. It features a straight whip style with an NMO base mount interface. The maximum power handling capacity is rated at 200 W. The physical height is limited to 18.000 inches (457.20 mm). The unit is RoHS compliant and classified under ECCN 5A991G.

Antennas RF Feature Summary

Engineered for installations lacking a suitable ground plane
Utilizes a heavy-duty chrome-plated loading coil for durability
Features a closed collinear design for omnidirectional coverage

Antennas RF Applications

Vehicular communication systems
Cellular network infrastructure
External mounting scenarios requiring no ground plane

Antennas RF Procurement Notes

Verify that the specific application environment supports the 806-866 MHz operational band. Confirm compatibility with NMO base mounts, as these are sold separately. Ensure the installation site accommodates the maximum height requirement of 18.000 inches. Check local regulations regarding RF emissions in the UHF spectrum before deployment.

Antennas RF Selection Notes

Select this model when a ground plane is unavailable or unsuitable for standard antenna operation. The 5 dBi gain offers balanced performance for vehicular use. Consider the NMO interface for secure vehicle mounting. Evaluate the 200 W power rating against transmitter output to ensure safety margins. The chrome plating provides environmental resistance for outdoor exposure.

Antennas RF Part Context

This component belongs to the TE Connectivity B8065 series of RF antennas. It is specifically engineered for UHF frequencies between 300 MHz and 1 GHz. The product line emphasizes solutions for mobile and vehicular platforms where traditional ground planes cannot be established. It serves as a specialized alternative to standard whip antennas requiring metal chassis grounding.
