CAF95956

Antennas RF Overview

The TE Connectivity CAF95956 is a panel-mount RF antenna designed for operation at the 900 MHz frequency band. It features an SMA female chassis connector for secure attachment to equipment enclosures. The component utilizes a micropshere design, which typically supports compact integration in space-constrained applications. This antenna serves as a dedicated radio frequency transmission and reception element within wireless communication systems requiring reliable signal propagation at the specified industrial or medical frequencies.

Antennas RF Feature Summary

• Operates specifically at the 900 MHz frequency band for targeted RF communication
• Features an SMA female chassis connector for robust panel mounting
• Utilizes a micropshere design for compact form factor integration

Antennas RF Applications

• Industrial wireless sensor networks
• Medical telemetry devices
• Remote monitoring systems

Antennas RF Procurement Notes

Verify the specific datasheet version and mechanical drawings prior to procurement. Confirm that the SMA female chassis interface matches the mating connector on the target enclosure. Ensure the 900 MHz operational frequency aligns with the system's regulatory requirements and intended application environment. Cross-reference the micropshere design specifications with available installation space constraints.

Antennas RF Selection Notes

Select this model when a dedicated 900 MHz solution is required rather than a multi-band alternative. The SMA female chassis mount is suitable for permanent installations where cable management is handled separately. Consider the micropshere geometry if low profile or specific radiation pattern characteristics are necessary for the deployment scenario.

Antennas RF Part Context

This component belongs to the TE Connectivity RF antenna portfolio, specifically categorized under panel-mount solutions. It is distinct from internal PCB antennas or external whip antennas due to its chassis mounting style. The product is engineered for consistent performance in fixed infrastructure or embedded device applications requiring stable RF connectivity.

Antennas RF Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing SMA connectors before considering alternative vendors.
