CDPZ06

Overview

The CDPZ06 is a mounting plate manufactured by nVent HOFFMAN, designed for use with their enclosure systems. It features a square footprint measuring 600 mm on each side and has a uniform thickness of 2.5 mm. The component is constructed from galvanized steel to provide corrosion resistance and structural stability for panel-mounted equipment. This plate serves as a foundational element for organizing internal components within industrial enclosures.

Feature Summary

• Constructed from galvanized steel for durability and environmental protection
• Provides a standardized 600 mm x 600 mm mounting surface
• Designed for automated drilling, tapping, and milling integration

Applications

• Internal organization of electrical components within industrial enclosures
• Support for control panels requiring standardized mounting grids
• Integration with automated panel preparation solutions

Procurement Notes

Verify the part number CDPZ06 against official nVent HOFFMAN documentation to confirm it is a mounting plate and not an enclosure body. Ensure compatibility with specific enclosure models such as the MAS or ASR series. Confirm material specifications match project requirements for galvanized steel construction.

Selection Notes

Select this component when a flat, rigid mounting surface is required inside a Hoffman enclosure. The 600x600 mm dimension aligns with standard modular chassis sizes. Consider the 2.5 mm thickness for adequate rigidity without excessive weight. Verify that the galvanized finish meets the environmental conditions of the installation site.

Part Context

This part belongs to the nVent HOFFMAN ecosystem of enclosure accessories. It complements modular chassis and wall-mount enclosures by providing a customizable interior structure. The product supports the brand's solution for creating ready-to-populate panels through automated processing techniques.

Replacement Considerations

No direct public substitute part numbers are identified in available documentation. Users should verify dimensional compatibility with existing enclosure frames before attempting substitution.
