CDR3P12

Overview

The CDR3P12 is a wall-mount junction box manufactured by Hoffman Enclosures, Inc. Constructed from steel with a gray polyester powder paint finish, this enclosure provides NEMA 12 and IP66 protection ratings for indoor use. It features a hinged door secured by screw clamps and includes an oil-resistant gasket to maintain environmental sealing. The unit measures approximately 12 inches in height, 8 inches in width, and 4 inches in depth, offering a compact footprint suitable for panel mounting applications requiring reliable electrical component protection.

Feature Summary

• Hinged door design with screw clamp closure mechanism
• Oil-resistant gasket ensures effective environmental sealing
• Continuous hinge construction for durable operation
• Gray polyester powder paint finish on interior and exterior surfaces

Applications

• Indoor industrial control panels
• Electrical junction points in manufacturing environments
• Panel-mounted equipment housing
• Protection of wiring and components against dust and oil

Procurement Notes

Verify the specific gauge thickness of the steel material upon ordering, as specifications may vary between 16 and 14 gauge depending on production batches. Confirm that the required knockouts are pre-formed or available as separate accessories if standard configurations do not meet installation needs. Ensure compatibility with existing panel cutouts before finalizing procurement decisions.

Selection Notes

Select this model when NEMA 12 and IP66 ratings are mandatory for indoor protection against falling dirt and dripping non-corrosive liquids. The compact dimensions make it ideal for space-constrained panel layouts. Consider the continuous hinge feature for frequent access requirements compared to lift-off cover alternatives.

Part Context

This component belongs to the Hoffman Enclosures line of steel junction boxes designed for general industrial use. It is part of a broader family of panel-mounted solutions that prioritize durability and environmental resistance. The product aligns with standard industry practices for protecting low-voltage electrical connections in controlled indoor settings.

Replacement Considerations

Cross-reference with other Hoffman steel enclosures sharing identical external dimensions and NEMA 12 ratings. Verify that substitute models maintain the same hinge type and gasket material specifications to ensure consistent performance and mounting compatibility.
