CFS69383P-30D43F

Antennas RF Overview

The CFS69383P-30D43F is a passive indoor antenna from TE Connectivity, designed for in-building wireless systems. It operates within a frequency range of 698 MHz to 3.8 GHz, supporting multiple cellular bands including LTE and CBRS. The unit features a low-profile design with a maximum height of 7.6 mm and utilizes a 4.3-10 female connector. It provides linear polarization and supports MIMO configurations. The antenna has a power rating of 50 W and an impedance of 50 Ohms. A 300 mm cable connects the module to the system.

Antennas RF Feature Summary

• Supports multi-band operation across 698 MHz to 3.8 GHz for diverse wireless standards
• Low-profile physical form factor suitable for ceiling mounting applications
• Utilizes 4.3-10 female connectors for secure RF interface connections

Antennas RF Applications

• LTE network infrastructure
• CBRS/WiMAX deployments
• WCS system integration
• AWS-3 band coverage

Antennas RF Procurement Notes

Verify the specific part number against official TE Connectivity documentation to ensure compatibility with existing RF infrastructure. Confirm that the 4.3-10 female connector type matches the mating hardware in the installation environment. Check RoHS compliance status if required by project specifications. Ensure the operating temperature range of -30°C to +70°C aligns with the intended deployment conditions. Validate cable length requirements prior to ordering.

Antennas RF Selection Notes

Select this model for indoor environments requiring wideband coverage from 698 MHz to 3.8 GHz. The low-profile design minimizes visual impact while maintaining performance. Ensure the installation location supports ceiling mounting methods. Verify that the 50 W power handling capacity meets the system's peak output requirements. Consider the 300 mm cable length for routing flexibility between the antenna and the radio unit.

Antennas RF Part Context

This component belongs to the CFD series of ultra-low-profile MIMO antennas by TE Connectivity. These antennas are engineered specifically for in-building distribution systems. The series emphasizes minimal height profiles to facilitate discreet installation in commercial and residential structures. The product line focuses on providing reliable signal distribution for modern cellular technologies.

Antennas RF Replacement Considerations

CFSA69383P-30D43F shares similar specifications but may differ in connector polarity or exact frequency sub-bands. CFD69383P variants offer comparable low-profile designs but require verification of connector types. Always cross-reference datasheets before substituting to ensure mechanical and electrical compatibility.
