CMD69273P-FNF

Antennas RF Overview

The CMD69273P-FNF is a multi-band RF antenna module manufactured by TE Connectivity, designed for cellular, WiMax, and WLAN applications. It operates across eight frequency bands, supporting protocols including Bluetooth, BLE, 4G, LTE, GPS, GLONASS, WLAN, ANT, Thread, Zigbee, Sub GHz, and UHF. The unit features a Sharkfin mechanical form with direct or permanent mounting style. It utilizes SMA Male and PL259 connector types for termination. The module supports indoor broadband low PIM 2-port MIMO omnidirectional ceiling mount configurations.

Antennas RF Feature Summary

• Multi-band support for cellular, WiMax, and WLAN applications
• Sharkfin mechanical form factor with direct or permanent mounting options
• Supports multiple communication protocols including Bluetooth, LTE, and WLAN
• Designed for indoor broadband low PIM 2-port MIMO omnidirectional use

Antennas RF Applications

• Cellular network infrastructure
• WiMax deployments
• WLAN connectivity systems

Antennas RF Procurement Notes

Verify the current manufacturing status of the CMD69273P-FNF before procurement, as it may be obsolete. Confirm compatibility with existing system requirements, including frequency bands and protocol support. Ensure that the SMA Male and PL259 connector types match the interface specifications of the connected equipment. Check for available substitutes if the part is no longer in production.

Antennas RF Selection Notes

Select this component for applications requiring multi-band RF antenna solutions with Sharkfin form factors. Consider its support for various communication protocols, including cellular, WiMax, and WLAN. Evaluate the need for direct or permanent mounting styles and ensure compatibility with SMA Male and PL259 connectors. Verify performance requirements against the module's operational capabilities.

Antennas RF Part Context

The CMD69273P-FNF belongs to the CMD series of antennas from TE Connectivity. It is designed for indoor broadband low PIM 2-port MIMO omnidirectional ceiling mount applications. The module supports multiple frequency bands and communication protocols, making it suitable for diverse wireless connectivity needs.

Antennas RF Replacement Considerations

Direct substitute: CMD69273P-30NF. Verify compatibility with existing system requirements before replacement.

Antennas RF FAQ

What is the mechanical form factor of the CMD69273P-FNF?

The CMD69273P-FNF features a Sharkfin mechanical form factor.

Which mounting styles are supported by the CMD69273P-FNF?

The CMD69273P-FNF supports direct or permanent mounting styles.

What connector types are used by the CMD69273P-FNF?

The CMD69273P-FNF uses SMA Male and PL259 connector types for termination.
