Arrays, Edge Type, Mezzanine (Board To Board) DF9-23P-1V(69) product image

DF9-23P-1V(69)

$0.80

Description：CONN HDR 23POS SMD GOLD
Series：DF9
Mfr：Hirose Electric Co Ltd
Package：Tape & Reel (TR)

SKU:cd559ddb75df Category: Arrays, Edge Type, Mezzanine (Board to Board) Brand: Hirose Electric Co Ltd

ChipApex WhatsApp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DF9-23P-1V(69) is listed in the Arrays, Edge Type, Mezzanine (Board To Board) range at ChipApex. The manufacturer field lists Hirose Electric Co Ltd. Its product description is CONN HDR 23POS SMD GOLD. Review the specifications below when checking this part for your BOM.

Arrays, Edge Type, Mezzanine (Board To Board) specifications for DF9-23P-1V(69)

Description：CONN HDR 23POS SMD GOLD
Series：DF9
Mfr：Hirose Electric Co Ltd
Package：Tape & Reel (TR)
Connector Type：Header, Center Strip Contacts
Number of Positions：23
Pitch：0.039" (1.00mm)
Number of Rows：2
Mounting Type：Surface Mount
Features：Board Guide, Solder Retention
Contact Finish：Gold
Contact Finish Thickness：8.00µin (0.203µm)
Mated Stacking Heights：4.3mm
Height Above Board：0.130" (3.30mm)

Arrays, Edge Type, Mezzanine (Board To Board) datasheet and documents for DF9-23P-1V(69)
