DSGP.1575.25.4.A.02

$7.30

Description：GPS 1575MHZ SMD CERAMIC DIRECT M
Series：-
Mfr：Taoglas Limited
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:359fdb31d4fb Category: RF Antennas Brand: Taoglas Limited

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DSGP.1575.25.4.A.02 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Taoglas Limited. Its product description is GPS 1575MHZ SMD CERAMIC DIRECT M. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for DSGP.1575.25.4.A.02

Description：GPS 1575MHZ SMD CERAMIC DIRECT M
Series：-
Mfr：Taoglas Limited
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.575GHz
Frequency Range：1.574GHz ~ 1.576GHz
Antenna Type：Ceramic Patch
Number of Bands：1
VSWR：-
Return Loss：-10dB
Gain：4.34dBi
Features：-
Termination：Solder
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.157" (4.00mm)
Applications：Galileo, GPS
Power - Max：-

Antennas RF datasheet and documents for DSGP.1575.25.4.A.02

DSGP.1575.25.4.A.02

Antennas RF Overview

The DSGP.1575.25.4.A.02 is a ceramic patch RF antenna manufactured by Taoglas Limited, designed for navigation applications including GPS and Galileo systems. It operates at a center frequency of 1.575GHz with a bandwidth ranging from 1.574GHz to 1.576GHz. The component features a gain of 4.34dBi and utilizes solder surface mount termination. Its physical dimensions include a maximum height of 0.157 inches (4.00mm). The antenna supports standard packaging options such as tape and reel, cut tape, and Digi-Reel.

Antennas RF Feature Summary

Supports dual-band reception for GPS and Galileo satellite navigation systems
Utilizes ceramic patch technology for stable RF performance
Designed for direct surface mount integration onto PCBs

Antennas RF Applications

GPS receiver modules
Galileo navigation devices
GNSS tracking hardware

Antennas RF Procurement Notes

Verify the specific ordering suffix and package variant required for production, as the manufacturer offers multiple handling options including tape and reel, cut tape, and custom reels. Confirm that the selected variant matches the automated assembly equipment specifications. Ensure compliance with RoHS3 standards and check moisture sensitivity level classifications prior to storage and reflow processes.

Antennas RF Selection Notes

Select this component when designing compact navigation circuits requiring integrated ceramic patch antennas. The surface mount profile suits space-constrained PCB layouts. Consider the specific gain requirements and frequency bandwidth compatibility with the target GNSS chipset. Evaluate mechanical mounting constraints against the specified maximum height dimension.

Antennas RF Part Context

This part belongs to the DSGP.1575 series of navigation antennas from Taoglas Limited. It represents a specialized solution for multi-constellation positioning within the UHF frequency group. The product line focuses on providing reliable signal acquisition for global navigation satellite systems in consumer and industrial electronics.
