EC3AW03

EC3AW03 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Cincon Electronics Co. LTD. Its product description is DC DC CONVERTER 15V 3W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for EC3AW03

• Description：DC DC CONVERTER 15V 3W
• Series：EC3AW (3W)
• Mfr：Cincon Electronics Co. LTD
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：200mA
• Power (Watts)：3 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-25°C ~ 71°C
• Efficiency：76%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 14 Leads
• Size / Dimension：1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE
• Standard Number：-

DC DC Converters datasheet and documents for EC3AW03
