EEU-EE2E820B

EEU-EE2E820B is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is CAP ALUM 82UF 20% 250V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for EEU-EE2E820B

• Description：CAP ALUM 82UF 20% 250V RADIAL TH
• Series：EE-A
• Mfr：Panasonic Electronic Components
• Package：Tape & Box (TB)
• Capacitance：82 µF
• Tolerance：±20%
• Voltage - Rated：250 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：10000 Hrs @ 105°C
• Operating Temperature：-25°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：588 mA @ 120 Hz
• Ripple Current @ High Frequency：1.68 A @ 100 kHz
• Lead Spacing：0.295" (7.50mm)
• Size / Dimension：0.709" Dia (18.00mm)
• Height - Seated (Max)：0.866" (22.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for EEU-EE2E820B
