F88G90E

Overview

The F88G90E is a 90-degree elbow component for lay-in wireway systems, manufactured by Hoffman Enclosures, Inc. It features an 8.00 x 8.00 inch internal cross-section and is constructed from mild steel with a gray painted finish. The unit weighs 17.2 lbs per piece and has a length of 10 inches. Designed for NEMA Type 1 applications, it provides protection against dust, dirt, oil, and water in environments where these elements are not severe hazards. The design allows any side to be removed while retaining the lay-in feature, secured by screws.

Feature Summary

• Retains lay-in functionality regardless of orientation due to removable sides
• Sides are secured together using screws for structural integrity
• Open design on one side facilitates wiring installation

Applications

• Lay-in NEMA Type 1 painted flat-cover wireway systems
• Electrical wiring protection in industrial environments
• Routing cables around corners in control panels or machinery

Procurement Notes

Verify that the specified application aligns with NEMA Type 1 requirements, as this component does not offer enhanced environmental sealing. Confirm that the 8x8 inch dimensions match the existing wireway system layout. Ensure compatibility with the associated straight runs and other fittings within the Hoffman Enclosures line. Check for any specific mounting hardware requirements not included with the elbow unit itself.

Selection Notes

Select this model when a 90-degree bend is required for 8x8 inch wireway runs. Consider the mild steel construction and gray paint for standard indoor industrial use. Evaluate the weight of 17.2 lbs for handling and support structure needs. Ensure the open-side design meets accessibility requirements for future maintenance or cable additions.

Part Context

This component belongs to the Hoffman Enclosures wireway accessories family, designed to complement their range of electrical distribution enclosures and wireways. It serves as a directional connector within larger wiring infrastructure projects. The product is part of a standardized system allowing modular expansion and modification of electrical pathways.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify dimensional compatibility with existing wireway systems before considering alternative manufacturers.
