FC-L03D

Power Line Filter Modules Overview

The FC-L03D is an EMC filter manufactured by Mornsun America, LLC. It is designed for power line filtering applications within industrial and commercial equipment. The component operates with a nominal voltage of 18-36VDC and provides a filtering capacity of 50W. It complies with RoHS standards, ensuring environmental safety in manufacturing processes. The unit is engineered to suppress electromagnetic interference on DC power lines, maintaining signal integrity and system stability under defined operating conditions.

Power Line Filter Modules Feature Summary

• Provides effective electromagnetic interference suppression for DC power lines
• Complies with RoHS environmental regulations for safe manufacturing
• Engineered for stable operation within specified industrial voltage ranges

Power Line Filter Modules Applications

• Industrial control systems requiring DC power line filtering
• Commercial electronic equipment needing EMI suppression
• Power supply input stages for noise reduction

Power Line Filter Modules Procurement Notes

Verify the exact part number FC-L03D against official Mornsun documentation before procurement. Confirm that the application requires a 50W DC EMC filter rated for 18-36VDC. Ensure compatibility with existing circuit designs regarding voltage ratings and physical mounting requirements. Cross-reference specifications with current datasheets to confirm compliance with relevant safety and environmental standards.

Power Line Filter Modules Selection Notes

Select this component when designing circuits that require robust EMI filtering for DC power inputs. Consider its 50W rating and 18-36VDC operational range to ensure it meets the specific power and voltage demands of the target application. Evaluate space constraints and mounting options to verify physical compatibility with the final assembly design.

Power Line Filter Modules Part Context

The FC-L03D belongs to Mornsun's family of EMC filters, specifically designed for DC power line applications. This series focuses on providing reliable noise suppression for sensitive electronic equipment. The component supports various industrial and commercial sectors by ensuring clean power delivery and reducing electromagnetic interference in critical systems.

Power Line Filter Modules Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
