FDR06CG03

Power Line Filter Modules Overview

The Curtis Industries FDR06CG03 is a single-stage DC EMC/EMI line filter module designed for chassis mounting. It features wire lead termination and operates with a rated voltage of 80VDC and a current capacity of 6A. The component utilizes a compact form factor suitable for space-constrained applications requiring effective noise suppression in power lines.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference (EMI) and radio frequency interference (RFI) suppression
• Designed for direct chassis installation to ensure stable grounding
• Utilizes wire leads for flexible integration into custom assemblies

Power Line Filter Modules Applications

• Industrial control systems
• Power supply input stages
• Electronic equipment requiring EMI compliance

Power Line Filter Modules Procurement Notes

Verify the specific voltage rating requirements against the datasheet, as some sources list 250VAC while official specifications indicate 80VDC. Confirm that the 6A current rating aligns with the application load. Ensure chassis mounting hardware is compatible with the unit's physical dimensions before procurement.

Power Line Filter Modules Selection Notes

Select this component when a single-stage solution is sufficient for noise reduction needs. Consider the wire lead configuration for ease of connection without additional PCB footprint constraints. Evaluate the thermal environment to ensure operation remains within safe limits under continuous load conditions.

Power Line Filter Modules Part Context

This part belongs to the FD series of line filters from Curtis Industries. The series offers various configurations for different voltage and current ratings. This specific model focuses on lower voltage DC applications compared to higher voltage AC variants in the same product family.

Power Line Filter Modules Replacement Considerations

Check for exact pinout and terminal type compatibility if substituting. Verify that alternative models meet the same 80VDC and 6A specifications. Ensure the replacement maintains similar physical dimensions for chassis mounting fit.
