FLLE2016AQDB

Power Line Filter Modules Overview

The KEMET FLLE2016AQDB is a single-phase EMI filter rated for 16 A and 300 V AC/DC at 50/60 Hz. It features quick connect terminals and chassis mounting. The unit operates between -25°C and +100°C, with an inductance of 800 uH. Dimensions are 70 mm length, 18 mm width, and 12.5 mm height.

Power Line Filter Modules Feature Summary

• Metallic case filled with self-extinguishing PU resin
• Single-stage attenuation design
• Quick connect terminal interface

Power Line Filter Modules Applications

• General purpose power line filtering
• Chassis mounted equipment noise suppression

Power Line Filter Modules Procurement Notes

Verify the specific suffix against official KEMET documentation to confirm terminal type and voltage ratings. Ensure the operating temperature range meets system requirements. Confirm compliance standards such as UL or IEC if required by the target application environment.

Power Line Filter Modules Selection Notes

Select this model for applications requiring 16 A current handling and 300 VAC rating. The quick connect interface suits automated assembly. Verify space constraints against the 70 mm length dimension.

Power Line Filter Modules Part Context

Part of the FLLE2 series, including P, Q, R, S, and U variants. These are general-purpose single-phase chassis mount EMI filters designed for robust noise suppression in industrial and commercial power systems.

Power Line Filter Modules Replacement Considerations

FLLE2020APDI is a related 20 A variant within the same series family.
