FLLE2100APXT6

Power Line Filter Modules Overview

The FLLE2100APXT6 is a DC-link EMI/RFI filter manufactured by KEMET, designed for high-power photovoltaic applications. It features a rated voltage of 1200 VDC and supports a ripple current of 250 A at 50°C. The component utilizes a robust construction suitable for demanding energy conversion environments, ensuring effective noise suppression while maintaining structural integrity under continuous electrical stress.

Power Line Filter Modules Feature Summary

• Engineered for high-voltage DC-link filtering in photovoltaic systems
• Capable of handling significant ripple current loads
• Provides effective electromagnetic interference suppression

Power Line Filter Modules Applications

• Photovoltaic inverters
• Solar power generation systems
• High-power DC-AC conversion units

Power Line Filter Modules Procurement Notes

Verify the specific suffix XT6 against official KEMET documentation to confirm packaging and tape specifications. Ensure the selected variant matches the required thermal and mechanical constraints for the target inverter design. Cross-reference the part number with the latest datasheet to confirm availability and compliance status before procurement.

Power Line Filter Modules Selection Notes

Select this component based on the system's 1200 VDC requirement and the need for 250 A ripple current capacity. Evaluate the physical dimensions and mounting requirements against the inverter layout. Confirm that the EMI suppression characteristics align with the regulatory standards applicable to the final solar energy equipment.

Power Line Filter Modules Part Context

This component belongs to the FLLE2-PV series, which is specifically developed for photovoltaic applications. The series addresses the unique challenges of solar inverters, including high voltage and current stresses. It represents KEMET's focus on providing specialized filtering solutions for renewable energy infrastructure.

Power Line Filter Modules Replacement Considerations

Consult official KEMET substitution guides for compatible alternatives. Verify that any substitute maintains the 1200 VDC rating and 250 A ripple current capability. Ensure dimensional compatibility and equivalent EMI performance before considering cross-brand or alternative series replacements.
