FM51OM1032

FM51OM1032 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Fairview Microwave. Its product description is ANTENNA 4.3-10 JACK 698 MHZ-4.2. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for FM51OM1032

• Description：ANTENNA 4.3-10 JACK 698 MHZ-4.2
• Series：-
• Mfr：Fairview Microwave
• Package：Bag
• RF Family/Standard：Cellular
• Frequency Group：Wide Band
• Frequency (Center/Band)：752MHz, 883MHz, 2.205GHz, 3.8GHz
• Frequency Range：698MHz ~ 806MHz, 806MHz ~ 960MHz, 1.71GHz ~ 2.7GHz, 3.4GHz ~ 4.2GHz
• Antenna Type：Dome
• Number of Bands：4
• VSWR：1.4
• Return Loss：-
• Gain：3.5dBi, 3dBi, 3.5dBi, 4dBi
• Features：Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m
• Termination：4.3/10 - Female
• Ingress Protection：-
• Grade：-
• Qualification：-
• Mounting Type：Bracket Mount
• Height (Max)：7.400" (187.96mm)
• Applications：5G, CDMA, GSM, LTE, LPWAN, LoRA, LTE-M, NB-IoT, IoT, M2M
• Power - Max：50 W
