FTRA6171M5PB-001

Antennas RF Overview

The TE Connectivity FTRA6171M5PB-001 is a 5G Phantom omnidirectional dome antenna designed for on-ground plane applications. It operates within a frequency range of 617 MHz to 7.125 GHz, covering multiple 5G bands including sub-6 GHz and mmWave spectrum. The component features a maximum gain of 5 dBi and utilizes an N-type female connector for panel mounting. It provides IP67 ingress protection and supports up to 100 W of power.

Antennas RF Feature Summary

• Omnidirectional radiation pattern suitable for broad coverage scenarios
• Integrated design optimized for operation on ground planes
• Robust construction with IP67 rating for environmental resistance

Antennas RF Applications

• 5G cellular infrastructure base stations
• Fixed wireless access (FWA) terminals
• Broadband wireless communication systems

Antennas RF Procurement Notes

Verify the specific suffix designation against technical requirements, as variations exist between black and white housing options. Confirm that the N-type female termination aligns with existing cabling infrastructure. Ensure the selected variant meets the required IP67 sealing standards for the intended deployment environment. Cross-reference the part number with official TE Connectivity documentation to validate current production status and lead times before finalizing procurement orders.

Antennas RF Selection Notes

Select this model when wideband coverage from 617 MHz to 7.125 GHz is required in a compact form factor. The on-ground plane design simplifies installation by eliminating the need for separate ground radials. Consider the 5 dBi gain profile for balanced performance across diverse 5G frequency allocations. Verify mechanical dimensions and mounting constraints to ensure compatibility with the target enclosure or pole structure.

Antennas RF Part Context

This component belongs to the 5G Phantom series, which offers low-profile cellular antennas engineered for modern wireless networks. The series emphasizes high efficiency and durability in challenging environments. The FTRA6171M5PB-001 specifically addresses the need for reliable connectivity across extensive frequency ranges while maintaining a compact physical footprint suitable for various mounting configurations.

Antennas RF Replacement Considerations

The FTRA6171M5PW-001 serves as a direct substitute, differing primarily in housing color rather than electrical performance. Both models share identical frequency ranges, gain specifications, and mounting interfaces. Verify that the visual distinction does not impact aesthetic requirements for the installation site.
