FTSH-109-04-F-MT-TR

Headers, Male Pins Overview

The FTSH-109-04-F-MT-TR is a high-reliability header strip manufactured by Samtec Inc. It features a 1.27mm (0.050 inch) pitch with 18 positions arranged in two rows. The connector utilizes surface mount right-angle termination and includes mixed technology tails for through-hole mounting. Contact materials are phosphor bronze with flash gold plating on the mating interface and tin on the tail. The insulator is black liquid crystal polymer rated UL94 V-0, supporting an operating temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Mixed technology design combining surface mount and through-hole termination options
• Flash gold plating provides cost-effective corrosion resistance
• Configurable post heights allow for flexible stacking solutions

Headers, Male Pins Applications

• Board-to-board interconnections
• High mating cycle applications
• Debug interfaces and sensor connections

Headers, Male Pins Procurement Notes

Verify the complete part number suffixes to ensure correct configuration. The '-F' indicates flash gold plating thickness, while '-MT' specifies the mixed technology tail style. Confirm that the required contact length matches the mating partner specifications. Ensure the ordering quantity aligns with the tape and reel packaging format provided by the manufacturer.

Headers, Male Pins Selection Notes

Select this component when mixed termination flexibility is required alongside standard 1.27mm spacing. The right-angle orientation aids in compact board layouts. Verify that the phosphor bronze material and LCP insulation meet the thermal and mechanical requirements of the target application environment.

Headers, Male Pins Part Context

This part belongs to the FTSH series of high-reliability header strips from Samtec. The series supports various configurations including vertical and horizontal orientations. It is designed for applications requiring robust performance and configurable stacking heights within the 1.27mm pitch family.

Headers, Male Pins Replacement Considerations

Compatible alternatives include FTSH-109-04-L-MT-TR for thicker gold plating or FTSH-109-04-S-MT-TR for selective gold plating. Vertical variants such as FTSH-109-04-F-DV-TR offer different mounting orientations.
