FTSH-110-01-F-MT

Headers, Male Pins Overview

The FTSH-110-01-F-MT is a high-reliability header strip from the Samtec FTSH series, designed for surface mount technology applications. This specific configuration features a right-angle orientation with 20 positions arranged in a dual row (2x10). The connector utilizes a 1.27mm (0.050 inch) pitch and employs phosphor bronze contacts with flash gold plating on the mating surfaces to ensure reliable signal transmission. It is rated for 3.4A per contact and operates within a temperature range of -55°C to 125°C. The housing is constructed from black liquid crystal polymer (LCP) with a UL94 V-0 flammability rating, providing robust mechanical stability and thermal resistance for demanding electronic assemblies.

Headers, Male Pins Feature Summary

• Surface mount right-angle termination design for compact PCB integration
• High mating cycle capability suitable for repeated connection requirements
• Configurable polarization and keying options to prevent incorrect installation
• Compliance with MIL-DTL-55302 testing standards for severe environments

Headers, Male Pins Applications

• High reliability interconnects requiring surface mount assembly
• Severe environment testing applications meeting MIL-DTL-55302 standards
• Systems utilizing Extended Life Product (E.L.P.) specifications
• Automotive A-Series product implementations

Headers, Male Pins Procurement Notes

Verify the exact suffix configuration against the official Samtec datasheet to confirm surface mount right-angle termination and pin count. Ensure compatibility with automated SMD placement equipment and reflow soldering profiles specified for LCP materials. Cross-reference the specific ordering code to validate contact plating thickness and insulation height requirements for the target PCB layout.

Headers, Male Pins Selection Notes

Select this component when surface mount technology is required for high-reliability connections. The right-angle form factor aids in space-constrained designs where vertical clearance is limited. Consider the FTSH series configurability for potential need in keyed or shrouded variants if environmental protection or misalignment prevention is critical for the specific application context.

Headers, Male Pins Part Context

This part belongs to the FTSH family of flexible stacking solutions and high-reliability header strips. The series offers extensive configurability including through-hole, surface mount, and mixed terminations in both vertical and horizontal orientations. It supports various post heights and end shroud options, making it a versatile choice for complex interconnect needs across industrial and automotive sectors.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify functional equivalence by matching pitch, current rating, termination type, and mechanical dimensions before considering alternative manufacturers.
