FTSH-116-01-L-DH-A-TR

Description：CONN HEADER SMD R/A 32POS 1.27MM
Series：FTSH
Mfr：Samtec Inc.
Package：Tape & Reel (TR)

SKU:de49079186c1 Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

FTSH-116-01-L-DH-A-TR is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN HEADER SMD R/A 32POS 1.27MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for FTSH-116-01-L-DH-A-TR

Description：CONN HEADER SMD R/A 32POS 1.27MM
Series：FTSH
Mfr：Samtec Inc.
Package：Tape & Reel (TR)
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.050" (1.27mm)
Number of Positions：32
Number of Rows：2
Row Spacing - Mating：0.050" (1.27mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.120" (3.05mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.135" (3.43mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Board Guide
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3.4A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for FTSH-116-01-L-DH-A-TR

FTSH-116-01-L-DH-A-TR

Headers, Male Pins Overview

The FTSH-116-01-L-DH-A-TR is a high-reliability header strip manufactured by Samtec. It features a 1.27 mm (0.05 in) pitch with 32 positions arranged in a dual-row configuration. The component utilizes surface mount termination with right-angle orientation and gold-plated phosphor bronze contacts. Designed for board-to-board applications, it operates within a temperature range of -55°C to +125°C and carries UL 94 V-0 flammability rating.

Headers, Male Pins Feature Summary

High mating cycle capability suitable for severe environments
Configurable surface mount and through-hole tail options
Gold flash plating for cost-effective reliability

Headers, Male Pins Applications

Board-to-board interconnections
High-speed data transmission systems
Industrial control modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffixes against the official Samtec datasheet to ensure correct termination style and row configuration. Confirm that the surface mount right-angle variant matches the target PCB footprint requirements. Cross-reference the contact material and insulation properties with system environmental constraints before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when high durability and precise 1.27 mm spacing are required for rigid board connections. Consider the right-angle surface mount profile for space-constrained layouts. Ensure compatibility with mating socket connectors regarding contact length and shroud design to maintain reliable electrical continuity.

Headers, Male Pins Part Context

This part belongs to the FTSH series of high-reliability header strips from Samtec. The series offers extensive configurability including various post heights and termination styles. It is engineered to meet or exceed MIL-DTL-55302 testing standards for robust performance in demanding electronic assemblies.
