FTSH-150-04-L-DH

$9.87

Description：CONN HEADER SMD R/A 100P 1.27MM
Series：FTSH
Mfr：Samtec Inc.
Package：Tube

SKU:ef85c2813558 Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

FTSH-150-04-L-DH is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN HEADER SMD R/A 100P 1.27MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for FTSH-150-04-L-DH

Description：CONN HEADER SMD R/A 100P 1.27MM
Series：FTSH
Mfr：Samtec Inc.
Package：Tube
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.050" (1.27mm)
Number of Positions：100
Number of Rows：2
Row Spacing - Mating：0.050" (1.27mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.150" (3.81mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.135" (3.43mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3.4A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for FTSH-150-04-L-DH

FTSH-150-04-L-DH

Headers, Male Pins Overview

The FTSH-150-04-L-DH is a high-reliability board-to-board header manufactured by Samtec Inc. It features a 1.27mm (0.050 inch) pitch with 100 positions arranged in two rows. The connector utilizes surface mount right-angle termination for secure PCB integration. Contacts are made of phosphor bronze with gold plating on the mating interface and matte tin on the termination side. The housing is constructed from black liquid crystal polymer (LCP) rated UL94 V-0, ensuring stability across a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

High-reliability design qualified to MIL-DTL-55302 standards
Configurable surface mount right-angle termination
Gold-plated contacts for enhanced conductivity and corrosion resistance

Headers, Male Pins Applications

Board-to-board interconnects requiring high reliability
Harsh environment electronic systems
Industrial control modules

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to ensure correct configuration. Confirm that the part number matches the required pin count and termination style. Check RoHS compliance status if restricted substances are a constraint. Ensure the ordering quantity aligns with standard packaging formats provided by the manufacturer.

Headers, Male Pins Selection Notes

Select this component when a robust, right-angle surface mount header is needed for dense signal routing. The 1.27mm pitch allows for compact layouts while maintaining reliable electrical connections. Consider the MIL-DTL-55302 qualification if the application involves significant mechanical stress or environmental exposure compared to standard commercial headers.

Headers, Male Pins Part Context

This part belongs to the FTSH series, which offers flexible stacking solutions and configurable terminal options. The series supports various termination styles including through-hole and mixed technology. The FTSH-150-04-L-DH specifically addresses needs for high-density, right-angle surface mounting with durable contact materials.
