GPED201-2802A001C1BH

Headers, Male Pins Overview

The GPED201-2802A001C1BH is a dual row, surface mount side entry pin header manufactured by Greenconn. It features 56 contacts arranged in two rows with a 1.27mm pitch spacing. The component utilizes high-temperature thermoplastic insulation and is designed for board-to-board connections. This series is characterized by its SMT termination method and right-angle orientation, suitable for automated assembly processes.

Headers, Male Pins Feature Summary

• Dual row configuration with side entry design for space-efficient mounting
• Surface mount termination compatible with standard SMT reflow processes
• High-temperature thermoplastic insulation material for thermal stability

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Automotive PCB systems requiring IATF16949 compliant components
• Consumer electronics manufacturing using surface mount technology

Headers, Male Pins Procurement Notes

Verify the exact contact count and physical dimensions against the official Greenconn datasheet before integration. Confirm that the specific ordering suffix matches the required mechanical orientation and termination style. Ensure compatibility with mating connectors from the same series to maintain proper alignment and electrical continuity during assembly.

Headers, Male Pins Selection Notes

Select this component when a dual row, 1.27mm pitch header is required for surface mount applications. Consider the side entry profile for board stacking constraints. Verify that the operating temperature range and current ratings meet the specific circuit requirements of the target electronic device.

Headers, Male Pins Part Context

This part belongs to the GPED201 series of pin headers from Greenconn Technology. The series offers various contact counts and configurations tailored for different board-to-board connection needs. Greenconn holds IATF16949 certification, indicating adherence to automotive quality standards for connector production.
