GRPB341VWVN-RC

Headers, Male Pins Overview

The GRPB341VWVN-RC is a vertical connector header manufactured by Sullins Connector Solutions. It features 34 positions with a 0.050-inch (1.27mm) pitch. The component utilizes through-hole termination for board mounting and includes unshrouded male pins. Designed for board-to-board or cable applications, it operates within a temperature range of -40°C to 105°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Vertical orientation design for direct board insertion
• Unshrouded male pin configuration for versatile mating
• Through-hole soldering termination method
• Push-pull locking mechanism for secure connection

Headers, Male Pins Applications

• Board-to-board interconnect systems
• Cable-to-board assembly connections
• General electronic equipment internal wiring
• Industrial control module interfaces

Headers, Male Pins Procurement Notes

Verify the specific part number against official manufacturer documentation to ensure compatibility with existing designs. Confirm that the required pin count and pitch match the target application requirements. Check for RoHS compliance status if environmental regulations apply. Ensure proper handling procedures are followed during storage and installation to maintain connector integrity.

Headers, Male Pins Selection Notes

Select this component when a high-density vertical header is required for reliable signal transmission. Consider the unshrouded design for flexibility in mating partner selection. Evaluate the thermal operating range to ensure suitability for the intended environment. Verify mechanical stability needs against the push-pull locking feature provided by this series.

Headers, Male Pins Part Context

This part belongs to the GRPBxx1VWVN-RC family of rectangular connectors from Sullins Connector Solutions. These headers are characterized by their vertical profile and standard 1.27mm spacing. The series supports various position counts while maintaining consistent electrical and mechanical specifications across different configurations.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 34-position, 1.27mm pitch vertical headers from Sullins such as GRPB341VWCN-RC. Ensure any replacement maintains the same through-hole termination and male pin type. Verify dimensional compatibility with existing PCB footprints before substitution.
