HFWLF24-203T

Common Mode Chokes Overview

The HFWLF24-203T is a through-hole common mode choke manufactured by Allied Components International. It features two lines and is rated for 250V AC/DC. The component provides an inductance of 20.5mH with a current rating of 3A. It operates within a temperature range of -25°C to +120°C and meets RoHS compliance standards.

Common Mode Chokes Feature Summary

• Provides common mode noise suppression for dual-line circuits
• Supports through-hole mounting for PCB integration
• Operates reliably across a wide industrial temperature range

Common Mode Chokes Applications

• AC/DC power supply input filtering
• EMI suppression in consumer electronics
• Industrial control system signal conditioning

Common Mode Chokes Procurement Notes

Verify the specific part number HFWLF24-203T against official Allied Components International documentation to confirm inductance, current rating, and package dimensions. Ensure compatibility with your circuit's voltage and thermal requirements before procurement.

Common Mode Chokes Selection Notes

Select this component when dual-line common mode noise reduction is required for 250V applications. Consider the 3A current rating and 20.5mH inductance values relative to your filter design needs. Verify through-hole footprint compatibility with your PCB layout.

Common Mode Chokes Part Context

This component belongs to the HFWLF24 series of common mode chokes from Allied Components International. The series offers various inductance values and current ratings for different EMI suppression requirements while maintaining consistent physical dimensions and mounting styles.

Common Mode Chokes Replacement Considerations

Check for direct substitutes within the HFWLF24 series or equivalent common mode chokes with matching 20.5mH inductance and 3A rating. Ensure voltage ratings and physical dimensions align with existing board space constraints.
