IL300-EF-X009T

Transistor, Photovoltaic Output Optoisolators Overview

The IL300-EF-X009T is a high linearity optocoupler from Vishay, featuring a single channel with an 8-SMD package. It provides an isolation voltage of 4420Vrms and supports AC/DC input types. The device utilizes a PIN photodiode output with linearized characteristics. Key electrical parameters include a maximum forward current of 60mA, a typical forward voltage of 1.25V, and a power dissipation of 210mW. Operating temperatures range from -55°C to +100°C. Rise and fall times are specified at 1.75µs. It complies with RoHS standards.

Transistor, Photovoltaic Output Optoisolators Feature Summary

• High linearity performance for accurate signal transmission
• Wide bandwidth exceeding 200kHz for fast response
• Linearized photovoltaic output for stable transfer gain

Transistor, Photovoltaic Output Optoisolators Applications

• Analog signal isolation in industrial control systems
• Precision measurement equipment interfaces
• Data acquisition system isolation channels

Transistor, Photovoltaic Output Optoisolators Procurement Notes

Verify the specific suffix EF against official Vishay documentation to confirm the exact gain class and bandwidth specifications required for your design. Ensure compatibility with surface mount assembly processes for the 8-SMD package. Cross-reference the isolation voltage rating of 4420Vrms with safety standards applicable to your target market. Confirm that the operating temperature range meets environmental requirements.

Transistor, Photovoltaic Output Optoisolators Selection Notes

Select this component when high linearity and wide bandwidth are critical for analog signal integrity. The IL300 series offers stable transfer gain compared to standard digital optocouplers. Consider the 8-SMD form factor for space-constrained PCB layouts. Evaluate the 4420Vrms isolation barrier for high-voltage separation needs. Compare against other IL300 variants if different gain or speed characteristics are needed.

Transistor, Photovoltaic Output Optoisolators Part Context

This part belongs to the IL300 family of linear optocouplers designed by Vishay Semiconductor Opto Division. The family is known for combining an LED emitter with a linearized photodiode array to achieve high fidelity. The IL300-EF variant specifically targets applications requiring enhanced bandwidth and linearity. It serves as a robust solution for isolating sensitive analog circuits while maintaining signal accuracy across varying conditions.

Transistor, Photovoltaic Output Optoisolators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
