IV2Q12030D7Z

$10.61

Description：GEN2, SIC MOSFET, 1200V 30MOHM,
Series：-
Mfr：Inventchip
Package：Tube

SKU:4efea53ec507 Category: Single FETs, MOSFETs Brand: Inventchip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IV2Q12030D7Z is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Inventchip. Its product description is GEN2, SIC MOSFET, 1200V 30MOHM,. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for IV2Q12030D7Z

Description：GEN2, SIC MOSFET, 1200V 30MOHM,
Series：-
Mfr：Inventchip
Package：Tube
FET Type：N-Channel
Technology：SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)：1200 V
Current - Continuous Drain (Id) @ 25°C：79A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：18V
Rds On (Max) @ Id, Vgs：39mOhm @ 30A, 18V
Vgs(th) (Max) @ Id：4.5V @ 12mA
Gate Charge (Qg) (Max) @ Vgs：135 nC @ 18 V
Vgs (Max)：+20V, -5V
Input Capacitance (Ciss) (Max) @ Vds：3000 pF @ 800 V
FET Feature：-
Power Dissipation (Max)：395W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：-
Qualification：-
Mounting Type：Through Hole
Supplier Device Package：TO-263-7
Package / Case：TO-263-7
