LN21RPHTA

LED Indication - Discrete Overview

The LN21RPHTA is a red diffused LED from Panasonic Electronic Components, featuring a round long top/bottom lens design. It operates at a wavelength of 700nm and is RoHS compliant. The device utilizes a rectangular package with a flat top, measuring 7.00mm by 3.00mm for the lens style size. This component is classified under discrete indicator LEDs, providing visual signaling capabilities through its diffused lens transparency.

LED Indication - Discrete Feature Summary

• Red light emission with diffused lens transparency
• Round long top/bottom lens geometry
• RoHS compliant construction

LED Indication - Discrete Applications

• Visual status indicators
• Panel mounting signals
• Discrete optical signaling

LED Indication - Discrete Procurement Notes

Verify component authenticity against Panasonic official documentation. Confirm RoHS compliance status and specific binning requirements for wavelength consistency. Ensure storage conditions maintain lead integrity prior to soldering processes.

LED Indication - Discrete Selection Notes

Select this part for applications requiring a 700nm red indicator with a specific 7.00mm x 3.00mm rectangular footprint. Consider the diffused output characteristics for uniform visibility needs in panel mount scenarios.

LED Indication - Discrete Part Context

This component belongs to the discrete optoelectronic category, specifically within the LED indicator segment. It serves as a fundamental visual signaling element in electronic assemblies, distinct from display or illumination arrays.

LED Indication - Discrete Replacement Considerations

Consult official Panasonic substitution guides for compatible alternatives. Verify mechanical dimensions and spectral output alignment before integrating substitute components into existing designs.
