M22-2020705

Headers, Male Pins Overview

The Harwin M22-2020705 is a 14-position double row vertical header connector from the M22 series. It features a 2mm pitch and is designed for through-board mounting with solder termination. The contacts are made of phosphor bronze with gold plating, rated for 1A current and 500V voltage. The housing is constructed from nylon, supporting an operating temperature range of -40°C to +105°C. The connector has no cover and utilizes a board-to-board system.

Headers, Male Pins Feature Summary

• Double row configuration with 14 contacts for high-density connections
• Vertical orientation suitable for standard PCB layouts
• Gold-plated phosphor bronze contacts ensure reliable electrical performance
• Nylon housing provides thermal stability within specified temperature ranges

Headers, Male Pins Applications

• Board-to-board interconnections in industrial electronics
• High-density circuit board assemblies requiring 2mm spacing
• Equipment operating within -40°C to +105°C environments

Headers, Male Pins Procurement Notes

Verify the part number M22-2020705 matches the required 14-pin double row specification. Confirm that the 2mm pitch and vertical orientation align with the PCB footprint design. Ensure the through-hole mounting method and solder termination type are compatible with the assembly process. Check that the nylon housing material meets the environmental requirements for the intended application.

Headers, Male Pins Selection Notes

Select this component when a 14-contact vertical header is needed for board-to-board applications. The 2mm pitch allows for compact designs compared to larger spacing options. The gold-plated contacts offer durability and conductivity. Consider the through-hole installation requirement and verify that the PCB layout supports the specific pin arrangement and tail length specifications.

Headers, Male Pins Part Context

This connector belongs to the Harwin M22 series, which offers various configurations including single and double rows in both vertical and right-angle orientations. The series is designed for PCB through-hole and surface mount applications, providing a versatile solution for different density and height constraints in electronic assemblies.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include Harwin M22-6361042 and M22-6341042, which are 20-position SMT sockets. Ensure that any substitute maintains the same 2mm pitch, contact count, and mechanical dimensions for proper fit and function.
