M22-2201046

Headers, Male Pins Overview

The M22-2201046 is a vertical male pin header from the Harwin M22 series, designed for board-to-board connections. It features a 2mm pitch with 10 positions in a single row. The connector utilizes phosphor bronze contacts with tin plating, rated for 1A per contact and 100V. Insulation is provided by black polyamide (PA6T) material, meeting UL94 V-0 flammability standards. It supports through-hole soldering and operates within a temperature range of -55°C to 105°C. The component has a mating stacking height of 8.05mm and includes all loaded pins.

Headers, Male Pins Feature Summary

• Vertical orientation design facilitates direct board-to-board mounting
• Polyamide insulation ensures high thermal stability and flame resistance
• Tin-plated phosphor bronze contacts provide reliable electrical conductivity

Headers, Male Pins Applications

• Board-to-board interconnects in compact electronic assemblies
• Signal routing in industrial control modules
• Connection interfaces for consumer electronics hardware

Headers, Male Pins Procurement Notes

Verify the specific datasheet version as this part number may be subject to End-of-Life status or production changes. Confirm that the tin-plated contact finish meets your corrosion resistance requirements. Ensure the through-hole footprint matches your PCB layout guidelines. Check for any recent Product Change Notifications regarding material substitutions or packaging updates before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a low-profile vertical header with a 2mm pitch is required. The 10-position configuration suits applications needing moderate signal density without occupying excessive board area. Consider the 1A current rating for power distribution limits. The PA6T insulation offers superior heat resistance compared to standard nylon, making it suitable for reflow processes requiring higher thermal endurance.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, a family of surface mount and through-hole connectors known for their robust mechanical design. The series offers various pin counts and orientations, including right-angle and vertical options. The M22-2201046 specifically represents the vertical, single-row variant with ten positions, providing a standardized solution for reliable interconnection in space-constrained environments.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Due to potential End-of-Life status, verify compatibility with existing footprints if sourcing alternatives. Cross-reference with other Harwin M22 series vertical headers for similar pitch and position requirements.
