M22-2201246

Headers, Male Pins Overview

The Harwin M22-2201246 is a 12-position, single-row male pin header from the M22 series. It features a 2mm pitch and is designed for through-hole mounting in board-to-board applications. The connector utilizes phosphor bronze contacts with tin plating and a black nylon housing. Rated for 1A current and 500V voltage, it operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Single-row male pin configuration for standard board-to-board interconnection
• Through-hole solder termination ensures secure PCB attachment
• Tin-plated phosphor bronze contacts provide reliable conductivity
• Black nylon insulation housing offers UL 94 V-0 flammability rating

Headers, Male Pins Applications

• General electronic equipment internal connections
• Industrial control system circuit boards
• Consumer electronics assembly
• Communication hardware interfaces

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating and orientation details against official datasheets. Ensure compatibility with mating socket assemblies regarding pitch and row alignment. Confirm RoHS compliance status if required by project specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row, 2mm pitch male header is required for through-hole implementation. Consider the 1A current rating and 500V voltage limit for circuit design constraints. Evaluate the operating temperature range and mechanical stability requirements for the target application environment.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, a comprehensive family of connectors offering various pin counts, rows, and orientations. The series supports both through-hole and surface-mount technologies, providing flexibility for diverse PCB layout needs across multiple industrial and commercial sectors.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2mm pitch, 12-position count, single-row male configuration, and through-hole termination method. Verify that alternative components maintain identical electrical ratings and housing material properties to ensure functional equivalence.
