M22-2210546

Headers, Male Pins Overview

Harwin M22-2210546 is a single-row vertical pin header with 5 positions and a 2.00mm pitch. It features tin-plated phosphor bronze contacts rated for 1A per contact. The housing is black nylon, UL94 V-0 rated, designed for through-hole solder termination. Operating temperature range is -40°C to 105°C. This board-to-board connector provides reliable interconnection in compact PCB layouts.

Headers, Male Pins Feature Summary

• Single-row vertical configuration for space-efficient board stacking
• Tin-plated contacts ensure corrosion resistance and stable conductivity
• Through-hole mounting supports robust mechanical attachment

Headers, Male Pins Applications

• Compact electronic device interconnects
• Industrial control module connections
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm plating type and orientation. Ensure compatibility with mating socket specifications regarding current rating and thermal limits before integration into final designs.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row vertical header is required. Consider the tin plating for cost-effective applications where gold plating is unnecessary. Verify that the 2.00mm pitch aligns with existing PCB footprint requirements.

Headers, Male Pins Part Context

The M22 series offers high-density interconnect solutions with 2.00mm spacing. This model represents a standard vertical header option within the range, suitable for general-purpose board-to-board connections requiring reliable signal transmission.

Headers, Male Pins Replacement Considerations

M22-2010546 serves as a potential alternative if different plating or orientation is acceptable. Cross-reference pin count and pitch strictly to ensure mechanical fit.
