M22-2210646

Headers, Male Pins Overview

The M22-2210646 is a male pin header connector from the Harwin M22 series, designed for board-to-board applications. It features a right-angle configuration with six positions arranged in a single row and a 2.00mm pitch. The connector utilizes phosphor bronze contacts with tin plating and is housed in natural polyamide (PA6T) insulation rated UL94 V-0. It supports through-hole termination and operates within a temperature range of -25°C to 85°C, carrying a 1A current rating per contact.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact vertical mounting on printed circuit boards.
• Single-row configuration provides efficient space utilization for low-pin-count connections.
• Tin-plated phosphor bronze contacts ensure reliable conductivity and corrosion resistance.

Headers, Male Pins Applications

• Board-to-board interconnections
• Compact electronic assemblies requiring right-angle routing
• Low-pin-count signal transmission

Headers, Male Pins Procurement Notes

Verify component authenticity by cross-referencing the manufacturer's part number with official datasheets. Confirm that the specific ordering suffix matches the required right-angle orientation and pin count. Ensure compliance with RoHS directives if applicable to your manufacturing standards before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this model when a right-angle male header is required for tight spatial constraints. The 2.00mm pitch suits dense layouts, while the PA6T insulation offers thermal stability. Verify that the operating temperature range meets system requirements and that the through-hole mounting style aligns with the PCB fabrication capabilities.

Headers, Male Pins Part Context

This component belongs to the M22 series, known for its robust construction and versatile mounting options. The M22-2210646 specifically addresses needs for angled connections in consumer electronics and industrial control modules where standard vertical headers are impractical due to height restrictions.

Headers, Male Pins Replacement Considerations

M22-2210646 is currently listed as obsolete or end-of-life. Engineers should evaluate compatible alternatives such as the M22-2210647 or similar right-angle headers from the same series, ensuring identical pitch, pin count, and mounting characteristics.
