M22-2410546

Headers, Male Pins Overview

The M22-2410546 is a pin header from the Harwin M22 series, designed for board-to-board connections. It features a 2 mm (0.079 in) pitch and consists of 10 positions arranged in a single row. The connector utilizes a right-angle orientation with through-hole termination for PCB mounting. Contact surfaces are tin-plated to ensure reliable electrical performance. The housing material is nylon, providing structural integrity for industrial applications.

Headers, Male Pins Feature Summary

• Right-angle configuration facilitates compact vertical space utilization
• Tin-plated contacts offer corrosion resistance and conductivity
• Through-hole installation ensures secure mechanical attachment

Headers, Male Pins Applications

• Board-to-board interconnects in industrial equipment
• High-density PCB layouts requiring right-angle routing
• Electronic assemblies with limited vertical clearance

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm contact plating and housing material specifications. Ensure the selected variant matches the required current rating and temperature range for the target application environment. Cross-reference the part number with authorized distributors to confirm availability and authenticity before procurement.

Headers, Male Pins Selection Notes

Select this component when a right-angle, single-row header with a 2 mm pitch is required. The tin-plated finish suits general-purpose applications where gold plating is not necessary. Consider the through-hole mounting style for robust mechanical stability. Evaluate the 1A current rating per contact against the circuit requirements to ensure adequate performance margins.

Headers, Male Pins Part Context

This part belongs to the M22 series, which offers various configurations including single and double rows with different pin counts. The series is characterized by its 2 mm pitch and compatibility with standard PCB manufacturing processes. Other variants in the family may feature different orientations or contact materials, necessitating careful selection based on specific design constraints.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires identical mechanical dimensions and electrical characteristics. Consult Harwin technical support for potential alternatives if this specific part number is unavailable.
